HDA MZMA Multi Zone Matrix Amp (6x4) 55,

The new Multi Zone Matrix Amplifier (MZMA) offers 8 channels of power in a space-saving 1U amplifier, delivering room-to-room high-quality audio in up to 4-zones.

Six inputs, four outputs and amplification in 1U. Minimal rack space, maximised performance. Choose between music or TV audio to route to any zone, room-to-room with grouping. 55W/channel, 42W all channels driven, analogue hi-fi with low noise. Analogue 3-band EQ, controllable zone volume, max volume and input gain adjustment. Combine MHUB PRO 2.0 with Multi Zone Matrix Amp (6x4) 55 (MZMA) and get the best of both worlds; pixel-perfect images with crystal clear and impactful sound. MZMA ships with uOS (uControl OS) on board meaning that the entire system can be controlled from the uControl app or remote. Control drivers - All major control systems are supported with control over zone volume, individual amp power state and switching included

TBC
Specification
Form factor: 19”/1U rack-mountable
Input / output / Line Out: 6 / 4 / 4
Input type: 3.5mm Stereo Jack (x4) Optical / Digital Coaxial (x2)
Output type: Amplified output (x4)
Input audio format support: Stereo
Max input level: +12dBu (+9.8dBv)
Input gain (2dB steps): -14dBu — +16dBu
Amplifier output power: 55W per channel at 4Ω / 30W per channel at 8Ω
Channel output level (1dB steps): 0dBu — -66dBu (1dB steps) -100dB mute
Max output level: -72dB — 0dB
Max output level (line-out) +16dBu (+14dBv)
EQ (2dB steps): Treble: +/- 14dB @ 10KHz / Mid: +/- 14dB @ 1KHz / Bass: +/- 14dB @ 100Hz
Balance (1dB steps): +/- 6dB
Power consumption (W) Min / Max: 14 / 360
Power (V) 110-240
Operating temperature (C): -10 — 60
Storage temperature (C): -15 — 70
Relative humidity: 5% — 95% non condensing
Housing: Steel
Colour: Grey (Carbonite)
Dimensions (W/D/H) mm 440 x 284 x 43
Weight (g): Chassis: 4700 / Package: 5750
Warranty: 2 Year Warranty, 5 years with Cloud Registration. (Cloud Registration must be completed within 30 days of installation for the extended warranty period to be activated).
Faulty From New*:
(Within 28 Days Of Purchase)		 Return to AWE for assessment.
Please complete this online Returns Form

Warranty Info

After 28 Days Of Purchase*:
(Within The Manufacturer's Warranty)
*Terms & Conditions: For further information regarding AWE's returns procedures please see chapters 7 & 8 in our Terms & Conditions

Features

  • Four unbalanced analogue stereo inputs (3.5mm stereo jack) Two digital inputs (Digital Coaxial & Optical)
  • 55W per channel at 4Ω (all channels driven @ 42W) 30W per channel at 8Ω (all channels driven @ 30W)
  • Fully analogue for superior sound quality reproduction
  • Adjustable analogue 3-band EQ
  • Adjustable input gain from -14dBu to +16dBu in 2dB steps
  • Power-saving amplifier shut-down (manual or automated) and low power modes
